Bearing steel ball/Gcr15

03

Bearing steel balls have good surface quality, high hardness, large load bearing, excellent wear resistance and deformation resistance, and are widely used in precision ball bearings, automotive parts, linear guides, slewing rings, and wind power generation.

Main production and operation of high, medium and low carbon steel balls, bearing steel balls, stainless steel balls and metal balls and non-metal balls of various materials and special technical requirements.

Product Category

Bearing steel ball

E-mail

henrychou@xinhuisteelball.com

Keywords:Bearing steel ball | Stainless steel ball | Carbon Steel Balls | Aluminum ball

Inquiry

Feature & Functions

Bearing steel balls have good surface quality, high hardness, large load bearing, excellent wear resistance and deformation resistance, and are widely used in precision ball bearings, automotive parts, linear guides, slewing rings, and wind power generation.



NanorCr
Material composition C Si Mn P S Cr
0.95-1.05% 0.15~0.35% 0.25~0.45% 0.03%Max 0.03%Max 1.40~1.65%
Mechanical properties tensile strength Yield strength density
325,000 psi 295,000 psi 0.283 lbs/cu in
Size range 0.8mm(1/32") to 63.5mm(2-1/2")
hardness HRC60～66
Grade G10～G1000
physical property No corrosion-resistant magnetism
application Used for precision ball bearings, auto parts, linear guides, slewing bearings, wind power generation, grinding media.
Brand ASTM/AISI DIN YB JIS
E52100 100Cr6 1.3505 GCr15 SUJ2
